1, mainly used in large-scale waste recycling company waste paper, carton, straw, straw baling loose material. 2, hydraulic configuration: low noise hydraulic circuit system, using imported and domestic high-quality components combination, both to ensure quality and reduce the cost, performance and stability of the machine. 3, electrical configuration: by using PLC control, which has the advantages of simple circuit, low failure rate, check and troubleshooting is simple and fast. 4, shear knife: selection of scissors design international, improve cutting efficiency and prolong the service life of the blade. 5, Wire bander: the newest type of wire, the saving wire, the fast banding, low failure rate, easy to clean maintenance and maintenance. 6, The length is set free to record the packaging values accurately. 7, The installation is simple, the foundation construction is simple, need not the ground to reinforce processing. 8, The installation must be equipped with a reservoir of no less than 20 cubic meters to cool the hydraulic oil Main technical parameters:

technical parameters					note
The main pressure cylinder	model number	190*230	travel	1500
	nominal thrust	120KN	quantity	Only one
Hydraulic system working pressure		120KN
The size of the feeding size		750*1100
Bag piece size		(width)750*(length)800* (The length of the adjustable)
Paper density		600KG/ Per cubic meter
The paper separator		2000mm-4500mm
Machinery probability		22KW+4.0KW+1/15 reduction gears			Including conveyor
Equipment specification		20 Square soft copper
Packing line		12# iron wire
Bales line number		4 root
Way to work		feedstock,compress package,Wear silk,Bundle of line fully automatic
The production efficiency		Ten packs per hour (left and right)
