Material Type:	Corrugated Cardboard	Packaging Type:	Cartons, Film, Case, Bottles, Belt
Voltage:	220V/380V/440V,380V 50hz 3phase	Color:	Optional
Driven Type:	Electric	Colors:	1-6 Colors
Application:	Carton Box Making Machine	Max Speed:	120 Pieces/min
Power Supply:	3-phase 380V/50Hz	Slotting Depth:	Adjustable
Printing Color:	Multi-color	Slotting Type:	Rotary Slotting

Performance of the main mechanisms: Designed According the high request and the reliable function,the operation of the machine is humanization,can accomplish the setting,revision, implement, replacing and memories function in a shot time,and display with a exact data. ◆ All the drive rollers adopted high quality steel materials,hard chromium plating and the surface treated by lapping finish. ◆ The drive gears adopt high quality alloy steel,after heat treatment and lapping finish. ◆ The main drive roller adopt keyless connect,decrease the connection gap, guarantee the printing precision. ◆ Lubricate oil automatic balance device,keep the equal oil level equal in each unit. ◆ The machine adopt PLC control,with”automatic zero return”and”memories”function. ◆ Use sun feeder for feed the cardboard. ◆ Customer can chose use steel anilox roller or ceramic roller,the lines of the anilox roller ac so can be chose accord the customer use Main technical parameter:
