details introduction :
1, mainly used in large-scale waste recycling company waste paper, carton, straw, straw baling loose material.
2, hydraulic configuration: low noise hydraulic circuit system, using imported and domestic high-quality components combination, both to ensure quality and reduce the cost, performance and stability of the machine.
3, electrical configuration: by using PLC control, which has the advantages of simple circuit, low failure rate, check and troubleshooting is simple and fast.
4, shear knife: selection of scissors design international, improve cutting efficiency and prolong the service life of the blade.
5, Wire bander: the newest type of wire, the saving wire, the fast banding, low failure rate, easy to clean maintenance and maintenance.
6, The length is set free to record the packaging values accurately.
7, The installation is simple, the foundation construction is simple, need not the ground to reinforce processing.
8, The installation must be equipped with a reservoir of no less than 20 cubic meters to cool the hydraulic oil
Main technical parameters:
technical parameters | note | ||||
The main pressure cylinder | model number | 190*230 | travel | 1500 | |
nominal thrust | 120KN | quantity | Only one | ||
Hydraulic system working pressure | 120KN | ||||
The size of the feeding size | 750*1100 | ||||
Bag piece size | (width)750*(length)800* (The length of the adjustable) | ||||
Paper density | 600KG/ Per cubic meter | ||||
The paper separator | 2000mm-4500mm | ||||
Machinery probability | 22KW+4.0KW+1/15 reduction gears | Including conveyor | |||
Equipment specification | 20 Square soft copper | ||||
Packing line | 12# iron wire | ||||
Bales line number | 4 root | ||||
Way to work | feedstock,compress package,Wear silk,Bundle of line fully automatic | ||||
The production efficiency | Ten packs per hour (left and right) |
