★ Yaskawa Japan imported dual-servo-driven,accurately precision, mechanical transmission are decreased, which can effectively reduce the mechanical failure rate.
★ Wei Lun touch screen operation, the parameter ( nail distance, nail number, nail types, tail gate) change conveniently.
★ The whole control system uses Omron PLC control system.
★ Electric control the tail gate, the use of stepper motor-driven, size accurate , size-changing is more convenient.
★ Keys control box uses the Siemens brand.
★ photoelectric and proximity switches is Schneider brand.
★ The under mold, blades is tungsten steel made in Japan (wearable)
★ entire nail heads group made of special steel , computer gong is precision making.
★ can nail single nail (/)Dual nail(/ /) strengthen nails (/ / / / / / two side are Dual nail, the middle part are single nail) once completed, can fit different customer requirements of different kinds of nails.
★ changing carton size and adjusting nails can be completed just one minute, saving time and easy operation.
★ can nail box with or without lid (with or without lid box should be informed to maker before machine making).
★ Department of automatic counting , feed units equipped with photoelectric sensors, when feeding, table automatically rise.
★ rear section with automatic counting function, the number of finished carton can be set (1-99) and transport to the machinery end, convenient for bundled package.
★ Mechanical speed: 500 nails / min
★ nails from :30-120mm (adjustable)
★ table lift Height :: 900mm
★ machine size: Host 2.8x2.7x2 m
★ Weight: 2000kg.
Max.(L+W)x2 | 2460mm | Length of machine | 2800mm |
Min.(L+W)x2 | 606mm | Width of machine | 2600mm |
Max.(W+H)x2 | 1515mm | weight | 2000kgs |
Min.(W+H)x2 | 400mm | Speed | 500 stitches/min |
Hight of feeder | 900mm | Stitching distance | 30-60mm |
Power | 6HP | Nails NO. | 1-99 nails |
No. | Name | brand | origin | Remarks |
01 | servo motor head | Yaskawa | Japan | |
02 | servo motor feed | Yaskawa | Japan | |
03 | PLC | Omron | Japan | |
04 | contactor relay | Siemens | Germany | |
05 | Reducer | Parker | Taiwan | 2 |
06 | Reducer | real reputation | Hangzhou | 2 |
07 | photoelectric proximity switch | Schneider | France | |
08 | touch screen | Wei Lun | Taiwan | |
09 | circuit breaker | Schneider | France | |
10 | universal joint | zhuyu | Taiwan | |
11 | bearing | renben | Jiangsu | |
12 | the whole set of Stud | Taiwan | ||
13 | blade | made of tungsten alloy steel | resistant to wear | |
14 | the under mold | making tungsten alloy steel | corrosion-resistant | |
15 | cylinder | solenoid valve | AIRTAC | Taiwan |
